| Connections |
|---|
| SDI Video Inputs | 2 |
| SDI Video Outputs | 2 |
| SDI Monitor Outputs | 1 |
| SDI Rates | 1.5G, 3G, 6G, 12G. |
| Built in Speaker | Mono |
| Analog Audio Inputs | 2 channel analog Program audio in supported via 9‑pin connector. |
| Analog Audio Outputs | 1 x 6.35 mm headphone jack. |
SDI Audio Input | Return 1 with 2 channels of Program audio embedded in 1.5G/3G/6G/12G-SDI.
4 talkback channels on 13, 14, 15 and 16.
Return 2 with 2 channels of audio embedded in 1.5G/3G/6G/12G-SDI. | | SDI Audio Output | 2 channels of Program audio embedded in 1.5G/3G/6G/12G-SDI.
4 talkback channels on 13, 14, 15 and 16. |
| Timecode Connections | 1 x BNC In, 1 x BNC Out. |
| Reference Connections | 1 x BNC In, 1 x BNC Out.
Tri-Sync or Black Burst. |
| Talkback Audio | SDI channels 13 and 14 for Engineering talkback.
SDI channels 15 and 16 for Production talkback.
RJ-45 Talkback connector for analog external talkback systems. |
| Screen | 2.2 inch LCD |
| Ethernet | 1 x 10Gb/s PoE RJ‑45 Camera connector for SMPTE Fibre style workflow over Cat 6A network cable.
1 x 1Gb/s for external control and software updates. |
| Computer Interface | 1 x USB-C. |
| Standards |
| HD Video Input Standards | 720p50, 720p59.94, 720p60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30
1080i50, 1080i59.94, 1080i60
|
| Ultra HD Video Input Standards | 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
|
| SDI Compliance | SMPTE 292M, SMPTE 372M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2081‑1,
SMPTE 2081‑10, SMPTE 2082‑1 and SMPTE 2082‑10. |
| 3G SDI | Auto detects SMPTE level A or B on SDI input. |
| SDI and HDMI Monitor Out Video Standards | 1080p50, 1080p59.94, 1080p60
|
| Video Streaming Standards | 720p25, 720p30, 720p50, 720p60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
|
| Audio Sampling | Television standard sample rate of 48kHz and 24‑bit. |
| Video Sampling | 4:2:2 |
| Color Precision | 10-bit |
| Color Space | REC 709, REC 2020. |
| Multiple Rate Support | SDI switches between HD, 3G-SDI, 6G-SDI and 12G-SDI. |
Control | | Built in Control Panel | 7 buttons with spin knob control and 2.2 inch color display for device control and menu settings. |
| External Control | RJ-45 1Gb/s Ethernet. |
Software | | Software Included | Camera Utility for firmware update. |
Operating Systems | Mac 10.15 Catalina,
Mac 11.1 Big Sur or later. | | Power Requirements |
|---|
| Power Supply | 100 - 240V AC input. |
| Power Supply | 1 x Internal 100 - 240V AC 50/60Hz. |
| Power Usage | 40 W max plus camera power usage. |
Optional Accessories | | Blackmagic Universal Rack Shelf | Blackmagic Studio Camera 4K Pro |
| Environmental Specifications |
|---|
| Operating Temperature | 0° to 45° C (32° to 104° F) |
| Storage Temperature | -20° to 45° C (-4° to 113° F) |
| Relative Humidity | 0% to 90% non-condensing |
| Warranty |
|---|
1 Year Limited Manufacturer's Warranty. |
