Type |
TTL secondary image-forming phase-difference detection using AF-dedicated sensor |
AF System / Points |
191 Point/155 f/4 cross-type AF points inc 1 dual cross type at f/2.8 1
The number of cross-type AF points will differ depending on the lens. |
AF working range |
EV -4 to 21 (at 20°C & ISO 100) |
AF Modes |
One Shot
AI Focus |
AF Point Selection |
Automatic selection: 191 point AF (inc face tracking and Eye AF)
Manual selection: Single point AF (selectable points all points, 61, 15, 9 or cross type only points selectable)
Manual selection: Spot AF
Manual selection: AF point Expansion 4 points (up, down, left, right)
Manual selection: AF point Expansion surrounding 8 points
Manual selection: Zone AF
Manual selection: Large Zone AF
AF points can be selected separately for vertical and horizontal shooting |
Selected AF point display |
Superimposed in viewfinder and indicated on LCD panel |
AF Lock |
Locked when shutter button is pressed half way or AF ON is pressed in One Shot AF mode. |
AF Assist Beam |
Emitted by an optional dedicated Speedlite |
Manual Focus |
Selected on lens |
AF Microadjustment |
Manual: Enter adjustment level +/- 20 steps
Adjust all lenses by same amount
Adjust up to 20 lenses individually
Adjust per lens serial number |
Viewfinder |
Pentaprism |
Coverage (Vertical/Horizontal) |
Approx. 100% |
Magnification |
0.76x 2 |
Eyepoint |
20 mm |
Dioptre Correction |
-3 to +1 dpt |
Focusing Screen |
fixed |
Mirror |
Quick-return all surface half mirror |
Viewfinder Information |
AF information: Single/Spot AF points, AF Frame, AF status, Focus indicator, AF mode, AF point selection, AF point registration
Exposure information: Shutter speed, aperture value, ISO speed (always displayed), AE lock, exposure level/compensation, flash metering, spot metering circle, exposure warning, AEB, metering mode, shooting mode, time
Flash information: Flash ready, high-speed sync, FE lock, flash exposure compensation, red-eye reduction light.
Image information: Card information, maximum burst (2 digit display), Highlight tone priority (D+).
Composition information: Crop area, Aspect ratio, Grid, Electronic level
Other information: Battery check, Warning symbol, Flicker Detection, drive mode, white balance, JPEG/RAW indicator |
Depth of field preview |
Yes |
Eyepiece shutter |
Built in |
Modes |
Program AE, Shutter priority AE, Aperture priority AE, Manual, 3x Custom settings |
Picture Styles |
Auto, Standard, Portrait, Landscape, Neutral, Faithful, Monochrome, Fine Detail, User Defined (x3) |
Colour Space |
sRGB and Adobe RGB |
Image Processing |
Clarity (8 levels)
Highlight Tone Priority (2 settings)
Auto Lighting Optimizer (4 settings)
Long exposure noise reduction
High ISO speed noise reduction (4 settings)
Lens optical correction:
- Peripheral illumination correction (stills and video)
- Chromatic aberration correction (stills and video)
- Distortion correction (during or after still photo shooting)
- Diffraction correction (stills and video)
- Digital Lens Optimizer (during or after still photo shooting)
Resize to M1, M2 or S 3
RAW image processing - during image Playback only
Crop images/rotate (3:2, 16:9, 4:3, 1:1, 2:3, 9:16, 3:4 ratios)
Multiple exposure |
Drive modes |
Single, Continuous L, Continuous H, Self timer (2s+remote, 10s+remote), S single soft shooting, continuous soft shooting |
Continuous Shooting |
Max. Approx. 16ps.
Max. 20 fps in Live View mode with mirror locked up with exposure and AF tracking
(speed maintained for unlimited number of JPEGs or over 1000 RAW images) 4 |
Type |
Electronic viewfinder with image sensor |
Coverage |
Approx. 100% (horizontally and vertically) |
Frame Rate |
For Stills 29.97 fps/for Movies 59.94 fps/29.97 fps (NTSC) 50.00 fps/25.00 fps (PAL) |
Focusing |
Manual Focus (Magnify the image 5x or 10x at any point on screen)
Autofocus: Dual Pixel CMOS AF (Face+Tracking
Spot AF
1-point AF
Expand AF area:
Expand AF area: Around
Zone AF
Large Zone AF: Vertical
Large Zone AF: Horizontal) |
Metering |
Real-time evaluative metering with image sensor (384-zone)
Partial metering (approx. 5.8% of Live View screen)
Spot metering (approx. 2.9% of Live View screen)
Center-weighted average metering
Active metering time can be changed |
Display Options |
Grid overlay (x3), Basic shooting information, Detailed shooting information, Histogram, Electronic Level |
Still Image Type |
JPEG: 10 compression options
HEIF: 10 compression options (10bit 422 BT2100)
RAW: RAW, CRAW
Complies with Exif 2.31 and Design rule for Camera File system 2.0
Complies with Digital Print Order Format [DPOF] Version 1.1 |
RAW+JPEG simultaneous recording |
Yes, any combination of RAW + JPEG/HEIF possible, separate formats to separate cards possible |
Image Size |
JPEG/HEIF: (L) 5472x3648, (M1) 4368x2912, (M2) 3648x2432, (S) 2736x1824
HEIF: 5472x3648
RAW: (RAW/C-RAW) 5472x3648 |
Folders |
New folders can be manually created and selected |
File Numbering |
(1) Consecutive numbering
(2) Auto reset
(3) Manual reset |
Movie Type |
RAW: CRM 12bit Audio: Linear PCM
MP 4 Video: 4K (8bit MPEG4 AVC/H.264, 10bit MPEG4/HEVC with Canon log), Full HD - MPEG4 AVC/H.264, Audio: Linear PCM
MP4 Video: Full HD IPB light - MPEG4 AVC/H.264, Audio: AAC |
Movie Size |
4K RAW (5496x2904) - (23.98, 24, 25, 29.97, 50, 59.94 fps)
4K DCI (17:9) - 4096x2160 (23.98, 24, 25, 29.97, 50, 59.94 fps) intra or inter frame
4K UHD (16:9) - 3840x2160 (23.98, 25, 29.97, 50, 59.94 fps) intra or inter frame
4K DCI cropped (17:9) - 4096x2160 (23.98, 24, 25, 29.97, 50, 59.94 fps) intra or inter frame
Full HD (16:9) - 1920x1080 (23.98, 24, 25, 29.97, 50, 59.94 fps) intra or inter frame plus IPB light |
Simultaneous recording |
Yes: RAW to card in slot 1 Proxy (MP4) to card in slot 2 |
Colour Sampling (Internal recording) |
4K - YCbCr4:2:2 (8-bit)
Full HD/HD - YCbCr4:2:0 (8-bit) |
Canon Log |
Yes Log 1 |
Movie Length |
4K and Full HD - Max duration 29 min 59 sec. (excluding High Frame Rate movies). No 4GB file limit with exFAT CF card. |
High Frame Rate Movie |
MOV Video: Full HD - 1920x1080 at 100 fps or 119.9 fps
Recorded as 1/4-speed slow motion movie
Single scene maximum recording up to 7 min 29 sec. |
4K Frame Grab |
8.3-megapixel JPEG still image frame grab from 4K movie possible |
Bitrate / Mbps |
5.5K RAW: (50/59.94p) Approx. 2600 Mbps (30/25/24/23.98p) Approx. 1800 Mbps
Canon Log off (H264 MP4)
4K DCI (50/59.94p): ALL-I Approx. 940 Mbps, IPB Approx. 230 Mbps
4K DCI (29.97p/25.00p/24.00p/23.98p): ALL-I Approx. 470 Mbps, IPB Approx. 120 Mbps
4K DCI cropped (50/59.94p): ALL-I Approx. 940 Mbps, IPB Approx. 230 Mbps
4K DCI cropped (29.97p/25p/24.00p/23.98p): ALL-I Approx. 470 Mbps, IPB Approx. 120 Mbps
4K UHD (50/59.94p): ALL-I Approx. 940 Mbps, IPB Approx. 230 Mbps
4K UHD (29.97p/25p): ALL-I Approx. 470 Mbps, IPB Approx. 120 Mbps
Full HD (119.90p/100p): ALL-I: Approx. 360 Mbps
Full HD (59.94p/50.00p): ALL-I: Approx. 180 Mbps
Full HD (59.94p/50.00p): IPB Approx. 60 Mbps
Full HD (29.97p/25p): ALL-I: Approx. 90 Mbps
Full HD (29.97p/25p): IPB: Approx. 30 Mbps
Full HD (29.97p/25p): IPB light: Approx. 12 Mbps
Canon Log on (H265 MP4)
4K DCI (50/59.94p): ALL-I Approx. 1000 Mbps, IPB Approx. 340 Mbps
4K DCI (29.97p/25.00p/24.00p/23.98p): ALL-I Approx. 470 Mbps, IPB Approx. 170 Mbps
4K DCI cropped (50/59.94p): ALL-I Approx. 1000 Mbps, IPB Approx. 340 Mbps
4K DCI cropped (29.97p/25p/24.00p/23.98p): ALL-I Approx. 470 Mbps, IPB Approx. 170 Mbps
4K UHD (50/59.94p): ALL-I Approx. 1000 Mbps, IPB Approx. 340 Mbps
4K UHD (29.97p/25p): ALL-I Approx. 470 Mbps, IPB Approx. 170 Mbps
Full HD (119.90p/100p): ALL-I: Approx. 470 Mbps
Full HD (59.94p/50.00p): ALL-I: Approx. 170 Mbps
Full HD (59.94p/50.00p): IPB Approx. 90 Mbps
Full HD (29.97p/25p): ALL-I: Approx. 135 Mbps
Full HD (29.97p/25p): IPB: Approx. 45 Mbps
Full HD (29.97p/25p): IPB light: Approx. 18 Mbps |
Microphone |
Built-in stereo microphones (48 kHz, 16-bit x 2 channels) |
HDMI Display |
External Monitor only, External Monitor only without information display or Simultaneous on camera and external monitor |
HDMI Output |
4K and Full HD recording, uncompressed YCbCr 4:2:0, 8-bit BT709, or YCbCr 4:2:2, 10-bit BT2020 with Canon Log sound output via HDMI is also possible |
Focusing |
Dual Pixel CMOS AF with Face Detection and Tracking AF, Movie Servo AF Manual Focus |
ISO |
100-25600 (in 1/3-stop increments) ISO can be expanded to or H1: 51200, H2: 102400, H3: 204800 (selected in Custom Function) |
Movie Digital IS |
Yes, image area when enabled: reduced by 10% |
