AJA Io Express

Code: BLO/AJA-IOEXPRESS-PCIE

Io Express delivers compact, powerful I/O for PC or Mac in the field, in the studio, or wherever your work takes you with 3G-SDI and HDMI I/O and Component Video Out.

For purchasing information

Enquire Now

Overview
Specifications

Io Express delivers compact, powerful I/O for PC or Mac in the field, in the studio, or wherever your work takes you with 3G-SDI and HDMI I/O and Component Video Out.

Cross-Platform Flexibility

However you choose to work, PC or Mac, laptop or desktop, Io Express can integrate seamlessly with your workflow.

The same Io Express unit can be used with PC or Mac - giving users the flexibilty to choose how they want to work in each scenario. A rear panel PCIe connector enables use with with a Mac Pro or Windows workstation via a PCIe card.

With the ability to rack mount two Io Express units in a single 1RU space, you can have a secure setup while still having the mobility to change locations quickly.

Desktop-Level Power to Go

Io Express is the perfect Mac or PC interface for anyone who needs a quality portable monitoring and mastering solution when working with Final Cut Pro X, Avid Media Composer/Symphony/Newscutter, Adobe Creative Suite, and more.

Rugged and portable, Io Express delivers desktop-level functionality that's powerful enough to deliver in the edit suite, but sturdy and portable enough to handle life in the field. With support for a wide range of analog and digital HD/SD video and audio I/O, and broadcast-quality HD to SD down-conversion, Io Express fits into any workflow with ease.

Compatible with PC or Mac, Io Express can be connected via a PCIe card (included), offering the flexibility to work on any platform, in the software of your choice.

Integrated AJA Down-Conversion

Featuring full 10-bit, broadcast-quality HD to SD hardware down-conversion and automatic HD/SD 12-bit component analog output, Io Express offers conversion flexibility all the time -- during ingest or playback.

Switchable Reference and LTC Input/Output

Many situations require the editing system to be locked in sync with other devices. Io Express can accept a reference signal, which ensures it is locked to any necessary devices for the best quality capture and output. This reference signal can then be passed on to other devices.

Users can select whether timecode is read off embedded signals or from an external input so that the proper timecode is always associated with any captured clips.

Powerful Connectivity

Io Express provides a wide variety of formats, frame rates and video/audio sources for the connectivity you need.

For digital video, Io Express features HDMI 1.3a I/O plus 3G/HD/SD-SDI I/O. In addition there are connections for Genlock or LTC input and a loop-through output, and component SD/HD analog video output. The high-quality deep color HDMI input and output provides complete color representation when you need it, while allowing you to interface with HDMI camcorders and HD monitors.

Io Express also offers support for both 8-channel HDMI and SDI embedded digital audio or 2 channels of unbalanced analog audio via two RCA connectors. For multi-channel audio mastering, the 8-channel SDI embedded 24-bit 48kHz audio provides pristine quality.

Extensive Software Support

AJA hardware is supported by an extensive list of professional software for editing, visual effects, graphics and more allowing the same AJA device to be used by many different applications on the same system. In addition, AJA provides several free applications that enable you to utilize the power of your AJA hardware even without having to run a particular software package. This allows you to create unique workflows without tying up valuable resources unnecessarily.

RS-422 Control

The RS-422 connection on Io Express enables control of external decks and other recording devices directly from within your software application of choice. Capture clips directly off tape and layoff sequences all frame-accurately without the need for a separate device control adapter.

Video Formats	(HD) 1080i 50, 59.94, 60 (HD) 1080PsF 23.98, 24 (HD) 1080p 23.98, 24, 25, 29.97, 30 (HD) 720p 50, 59.94, 60 (SD) 625i 50 (SD) 525i 59.94
Video Input	SD/HD SDI, SMPTE-259/292/296/424, 8 or 10-bit Single Link 4:2:2 (1x BNC) HDMI v1.3
Video Output Digital	SD/HD SDI, SMPTE-259/292/296/424, 8 or 10-bit Single Link 4:2:2 (1x BNC) HDMI v1.3
Video Output Analog	Composite/S-Video (Y/C) (1x BNC) NTSC, NTSCJ, PAL Component (3x BNC) HD: YPbPr, RGB SD: YPbPr, RGB (component mode) SMPTE/EBU N10, Betacam 525 line, Betacam 525J, RGB 12-bit D/A, 8x oversampling +/- .2 dB to 5.0 mHz Y frequency response +/- .2 dB to 1 mHz C frequency response .5% 2T pulse response <1% Diff Phase <1% Diff Gain <1 ns Y/C delay inequity
Audio Input Digital	8-Channel, 16 and 24-bit SMPTE-259 SDI embedded audio, 48 kHz sample rate, synchronous 8-Channel, 16 and 24-bit HDMI embedded audio, 48 kHz sample rate, synchronous
Audio Output Digital	8-Channel, 16 and 24-bit SMPTE-259 SDI embedded audio, 48 kHz sample rate, synchronous 8-Channel, 16 and 24-bit HDMI embedded audio, 48 kHz sample rate, synchronous
Audio Output Analog	2-Channel 16 and 24-bit unbalanced audio (via RCA jack)
Reference Input or LTC Input	1x BNC assignable to Reference video or LTC input
Reference	Analog Color Black (1V) or Composite Sync (2 or 4V) Nonterminating
Electrical Interface	PCI Express X1
Size (w x d x h)	8.74" x 7.09" x 1.65" (222.0 x 180.09 x 41.91 mm)
Weight	1.5 lbs (0.7 kg)
Power	12-18V, 11-13W
Environment	Safe Operating Temperature: 0 to 40 C (32 to 104 F) Safe Storage Temperature (Power OFF): -40 to 60 C (-40 to 140 F) Operating Relative Humidity: 10-90% noncondensing Operating Altitude: <3,000 meters (<10,000 feet)
