Portkeys MT22DS 21.5-inch Production Monitor

Code: BLO/PK-MT22-DS
$3,460.00

The Portkeys MT22DS is a 21.5-inch professional high-brightness production monitor with 1,000nits of brightness, a rugged aluminum alloy construction, two 3G-SDI, one GPI, and one HDMI input ports

Add to Cart

Found this item cheaper elsewhere? Let us know

ENQUIRE NOW

Got a question about this product?
Send us a message

Special Order Item

Usually ships in 2-4 weeks

Request ETA

What's In The Box?

  • 1x MT22DS Monitor
  • 1x Folding Holder
  • 1x Micro USB Flash Drive
  • 1x Power Cable 12V8A
  • 1x M2.5 Inner Allen Key
  • 1x Crystal Drop Rubber Button

    • The Portkeys MT22DS is a 21.5-inch professional high-brightness production monitor with 1,000nits of brightness, a rugged aluminum alloy construction, two 3G-SDI, one GPI, and one HDMI input ports, one 3G-SDI and one HDMI output ports with cross-conversion, two XLR audio outputs with 48V phantom power, and a complete set of precise monitoring tools.

    Key features

    • 21.5-inch, 10-bit panel with a resolution of 1920 x 1080 and a 1000:1 contrast ratio.
    • Daylight viewable with a maximum brightness of 1,000nits.
    • Factory color-calibrated: 100% coverage of Rec.709.
    • 2 x 3G-SDI input, 1 x GPI input, 1 x HDMI input, 1 x HDMI output, 1 x 3G-SDI output with cross-conversion from every direction.
    • Two XLR audio outputs with 48V phantom power.
    • Split screen monitoring, you can monitor two video inputs simultaneously.
    • Professional monitoring tools: Waveform, Vectorscope, Anamorphic, Peaking, ARRI False Color.
    • 3D LUT monitoring and 3D LUT SDI output capabilities.
    • Multiple function buttons for easy access to your favorite monitoring tools.
    • V-Mount / Gold Mount battery plate. 4-pin XLR 12-24V power input.
    • Built-in Sony NP-F battery plates with pass-through power to power wireless video receivers.
    • VESA mounting points at the back of the monitor.
    • Built-in carrying handle and comes with a removable table stand.
    • Rugged all-aluminum housing with 1/4″-20 mounting points on the sides.
    Specifications
    Screen Size 21.5″
    Dimension 523.6*320.6*65.8mm
    Viewing Angle 80/80/80/70
    Brightness 1000nit
    Resolution 1920*1080
    Contrast Ratio 1000:1
    Weight 5.8kg
    Color Gamut Rec.709
    Maximum Power 60W
    Material Aluminum Alloy
    Input Voltage DC 12-24V
    Fan Yes
