System |
Lens mount |
RF mount |
Sensor |
35mm full-frame CMOS sensor |
Number of pixels |
Total pixels: approx. 26.7 megapixels
Effective pixels: up to approx. 19 megapixels |
ISO sensitivity |
160-25600 (Extended: 100-102400) |
BASE ISO |
800 / 3200 / 12800 / Auto-change (Ex.: Canon Log 2, Canon Log 3, RAW recording) |
Sensor mode |
Full-frame, Super 35mm Crop, Super 16mm Crop |
ND filter |
Mechanical ND filter (2 / 4 / 6 / 8* / 10 stops*)*With extender |
Gamma |
Canon Log 2, Canon Log 3, Canon 709, BT.709 Wide DR, BT.709 Standard, PQ, HLG |
Frame rate |
6K 59.94P/50.00P (RAW)
4.3K 59.94P/50.00P(RAW)
4K 59.94P/50.00P (RAW/XF-AVC/XF-HEVC S/XF-AVC S)
2K 59.94P/50.00P (RAW/XF-AVC/XF-HEVC S/XF-AVC S) |
Color space |
Cinema Gamut, BT.2020 Gamut, BT.709 Gamut |
White balance |
Auto, sunlight, tungsten, color temperature (2000K to 15000K), settings A/B |
Dynamic range |
16 stops |
AF |
Dual Pixel CMOS AF II |
Recording Format |
Movies: Cinema RAW Light, XF-AVC, XF-HEVC S, XF-AVC S
Photos: JPEG |
Maximum frame rate* (slow & fast, etc.) |
Full-frame 6000x3164/60P
Super35mm Crop 4368x2304/100P, 4096x2160/120P
Super16mm Crop 2184x1152/180P |
Recording format (audio) |
Linear PCM 24-bit/48kHz/4ch, AAC 16-bit/48kHz/2ch (XF-HEVC S / XF-AVC S) |
Recording media |
CFexpress card, SD card |
LCD monitor |
3.5-inch LCD 2.76 million dots, touch panel |
Viewfinder |
No |
Multi-function shoe |
(21 pin) Yes (with power contacts) |
Wi-Fi |
Internal |
Input/Output Terminals |
LENS I/O |
Yes |
SDI OUT |
Yes (BNC terminal x1, 12G/6G/3G/HD-SDI) |
MON. |
Yes (BNC terminal x1, 3G/HD-SDI) |
HDMI |
Type-A |
INPUT |
Mini-XLR x2 (AES/EBU not supported) |
Ethernet |
Yes |
USB |
USB Type-C, for smartphone connection |
VIDEO |
USB Type-C*1, for LCD connection |
GRIP |
USB Type-C*1, for grip connection |
MIC |
Φ3.5mm stereo mini jack |
Headphone |
Yes (stereo) |
REMOTE A |
(φ2.5mm) Yes (REMOTE terminal) |
REMOTE B |
(RS-422) No |
TC (TIME CODE) |
Yes (DIN terminal) |
G-LOCK |
Yes (DIN terminal)*2 |
SYNC |
Yes (DIN terminal)*2 |
RET |
Yes (DIN terminal)*2 |
DC-IN |
12V XLR (4-pin) |
Power/Other |
Battery |
BP-A30N, BP-A60N |
Operating temperature |
Guaranteed performance conditions: Approx. 0 ℃ to 40 ℃ 85% (relative humidity)
Guaranteed operating conditions: Approx. -5 ℃ to 45 ℃ 60%(relative humidity) |
Dimensions (W x H x D) |
Approx. 142 x 135 x |
