Bright Tangerine Top Plate QR Dovetail

Code: BRI/B4002.1070
$170.00
This Standard riser for the RED KOMODO & KOMODO-X mounts to the LeftField 15mm LWS Baseplate core and sets your camera to the correct height for use with 15mm LWS rods.

ENQUIRE NOW

Got a question about this product?
Send us a message

Special Order Item

Usually ships in 4-6 weeks

Request ETA

This Standard riser for the RED KOMODO & KOMODO-X mounts to the LeftField 15mm LWS Baseplate core and sets your camera to the correct height for use with 15mm LWS rods. It features a slotted design to allow the camera to be balanced on the riser.

Compatible with RED KOMODO-X & KOMODO

The riser comes with two sets of washer plates that are uniquely designed to match the screw spacing of RED KOMODO or KOMODO-X. Each plate accommodates a 1/4″ & 3/8″ screw.

To mount your KOMODO, opt for the plate with screw holes spaced closer together (12.5mm). For the KOMODO-X, choose the plate with screw holes spaced further apart (25mm).

Interchangeable Risers

This is just one of the many risers in our range designed for the LeftField 15mm LWS Baseplate. Switching camera systems is made easy by simply swapping this riser to achieve the correct 15mm LWS height for your camera.

The riser connects to the LeftField 15mm LWS Baseplate using six screws provided.

No Compromises

Machined and hand-finished in our single factory in Church Crookham from high-grade materials. Hard anodised for extended durability. Every riser comes with our famous Bright Tangerine Support and the addition of a 2-year warranty.

Key Features

  • Set up your RED KOMODO-X & KOMODO with the LeftField 15mm LWS Baseplate using this Standard Riser.
  • It places the camera at the correct height to use with 15mm LWS accessories and support.
  • Compatible with RED KOMODO & KOMODO-X to set 15mm LWS height standards
  • Interchangeable riser for LeftField 15mm LWS Baseplates
  • Rubber pads prevent the camera from twisting
  • Slotted design allows for camera position to be balanced on the riser.
  • Includes captive screw mounting kit for RED KOMODO & KOMODO-X
  • Specifications
    Weight 0.19 kg
    Dimensions 8.8 × 6 × 3.7 cm
    Camera Brand

    RED

    Camera Model

    RED KOMODO, RED KOMODO-X
