Canon EOS C80 Full Frame 6K Cinema Camera

Code: CAN/C80

$8,899.00

Expected to begin shipping November 2024

Stay nimble with the compact EOS C80, with its mighty 6K full frame BSI sensor, RF mount and Dual Pixel CMOS AF II technology to deliver outstanding imaging and flexibility in your cinema, live and virtual productions.

Add to Cart

Found this item cheaper elsewhere? Let us know

ENQUIRE NOW

Special Order Item

Usually ships in 1-2 weeks

Request ETA

Overview
Specifications

Elevate Your Creativity

Stay nimble with the compact and ergonomic EOS C80, with its mighty 6K full frame BSI sensor, plus RF mount and Dual Pixel CMOS AF II technology to deliver outstanding imaging and flexibility in your cinema, live and virtual productions.

A Closer Look At The EOS C80

Discover the key highlights in the EOS C80 that support your professional video productions.

6K full frame BSI sensor

Backside illuminated (BSI) sensor technology delivers outstanding dynamic range, organic colour reproduction and a triple base ISO system resulting in low-noise performance.

Features

Full frame 6K BSI sensor

Next-generation backside illuminated design maximises light sensitivity with 16 stops of dynamic range
Triple base ISO

For optimal signal-to-noise ratio at 800 / 3200 / 12800 ISO
RF mount system

Enhanced imaging system platform also adaptable to PL and EF mounts
Dual Pixel CMOS AF II

Including EOS iTR AF X for tack-sharp auto focus across the full sensor
Cinema RAW Light

Record 12-bit internally for maximum flexibility in post-production
XF-HEVC S, XF-AVC S, and XF-AVC

Oversampled 4K 4:2:2 10-bit MP4 / MXF formats with detailed metadata
HDR

Produce high dynamic range content with Canon Log 2 / 3, PQ, and HLG
5-axis image stabilisation

Combine Electronic IS with Optical IS for the most stable cinematic footage
Two card slots

Record to SD UHS-II
Professional I/O

Extensive professional connectivity including 12G-SDI.
Robust and compact

Versatile design adaptable to your shooting style
Active cooling

Quiet, efficient cooling for long recording times

Full frame 6K BSI sensor

Capture breathtaking footage with Canon’s cutting-edge backside illuminated (BSI) stacked CMOS sensor, delivering next-generation capabilities, triple base ISO (800 / 3200 / 12800), organic colour reproduction, and 16 stops of dynamic range.

Dual Pixel CMOS AF II with EOS iTR AF X

Enjoy updated, faster auto focus technology. Pin-sharp and ultra-responsive face, eye, head, body, and animal tracking covering the full sensor. Have full control with face-only recognition and customisable settings to help ensure your focus never slips.

Compact, ergonomic and familiar design

A familiar and updated design delivers improved ergonomics, connectivity, plus updated joystick and multi-function shoe. Use the top handle or build your own rig, with flexibility to shoot your way in challenging conditions.

Professional recording formats and high frame rates

Including 12-bit Cinema RAW Light LT up to 6K 30P, and 4:2:2 10-bit up to 4K 120P. Oversampled 4K is available via XF-AVC and improved XF-AVC S / XF-HEVC S (MP4) formats, all featuring detailed metadata and filename structures. Output HDMI RAW to compatible external recorders.

RF mount

Rely on cutting-edge prime, zoom, and cinema lenses for unrivalled optical performance, real-time lens metadata, and ultra-responsive AF/IS systems. Easily use your PL and EF lenses with a Canon mount adapter.

Uncompromised connectivity

Professional on-body I/O includes 12G-SDI, HDMI, 2x mini-XLR, Mic In, Remote, and Timecode. Built-in Wi-Fi / Ethernet enables real-time IP streaming (SRT / RTSP) and remote control via XC Protocol and Multi-Camera Control app. Expandable with Canon’s Multi-Function Shoe.

Designed for the future

Real-time lens metadata output and capture for VP and VFX with support for Unreal Engine and After Effects, including distortion correction data. And create immersive VR experiences with Canon’s RF 5.2mm F2.8L Dual Fisheye lens.

Specifications

Key Specs

Lens Mount	Canon RF
Sensor Resolution	Actual: 26.67 Megapixel (6202 x 4300) Effective: 19.05 Megapixel (6008 x 3170)
Image Sensor	Full-Frame BSI Stacked CMOS
Image Stabilization	Digital, 5-Axis
ISO Sensitivity Range	100 to 102,400
Internal Recording Modes	Cinema RAW Light 12-Bit UHD 6K (6000 x 3164) from 1 to 29.97 fps [553 to 639 Mb/s VBR] 4368 x 2304 from 1 to 29.97 fps [678 Mb/s VBR] XF-AVC Intra 4:2:2 10-Bit 4096 x 2160 from 1 to 60.00 fps [240 to 600 Mb/s VBR] 3840 x 2160 from 1 to 60.00 fps [240 to 600 Mb/s VBR] 2048 x 2160 from 1 to 120 fps [120 to 300 Mb/s VBR] 1920 x 1080 from 1 to 120 fps [120 to 300 Mb/s VBR] XF-AVC Long GOP 4:2:2 10-Bit 4096 x 2160 from 1 to 120 fps [130 to 250 Mb/s VBR] 3840 x 2160 from 1 to 120 fps [130 to 250 Mb/s VBR] 2048 x 1080 from 1 to 180 fps [50 Mb/s VBR] 1920 x 1080 from 1 to 180 fps [25 to 50 Mb/s VBR] XF-AVC S Intra 4:2:2 10-Bit 4096 x 2160 from 1 to 60.00 fps [240 to 1200 Mb/s VBR] 3840 x 2160 from 1 to 60.00 fps [240 to 1200 Mb/s VBR] 2048 x 1080 from 1 to 120 fps [120 to 300 Mb/s VBR] 1920 x 1080 from 1 to 120 fps [120 to 300 Mb/s VBR] XF-AVC S Long GOP 4:2:2 10-Bit 4096 x 2160 from 1 to 120 fps [150 to 250 Mb/s VBR] 3840 x 2160 from 1 to 120 fps [150 to 250 Mb/s VBR] 2048 x 1080 from 1 to 180 fps [50 Mb/s VBR] 1920 x 1080 from 1 to 180 fps [50 Mb/s VBR] XF-AVC S Long GOP 4:2:0 8-Bit 4096 x 2160 from 1 to 120 fps [100 to 150 Mb/s VBR] 3840 x 2160 from 1 to 120 fps [100 to 150 Mb/s VBR] 2048 x 1080 from 1 to 180 fps [35 Mb/s VBR] 1920 x 1080 from 1 to 180 fps [35 Mb/s VBR] XF-HEVC S Long GOP 4:2:2/4:2:0 10-Bit 4096 x 2160 from 1 to 120 fps [135 to 225 Mb/s VBR] 3840 x 2160 from 1 to 120 fps [135 to 225 Mb/s VBR] 2048 x 1080 from 1 to 120 fps [35 Mb/s VBR] 1920 x 1080 from 1 to 120 fps [35 Mb/s VBR]

External Recording Modes	SDI/BNC / HDMI / USB 4096 x 2160
Media/Memory Card Slot	Slot 1: SD/SDHC/SDXC Slot 2: SD/SDHC/SDXC
Video I/O	1x BNC (12G-SDI) Output 1x BNC (3G-SDI) Monitor Output 1x HDMI (Unspecified Signal) Output
Mobile App Compatible	Yes: iOS Only App Name: Remote Camera Control App Functionality: Adjust Settings, Remote Control, View Live Feed
Battery Type	Canon BP-AN Series

Imaging

Lens Mount	Canon RF
Lens Communication	Yes, Cooke /i
Sensor Resolution	Actual: 26.67 Megapixel (6202 x 4300) Effective: 19.05 Megapixel (6008 x 3170)
Image Sensor	Full-Frame BSI Stacked CMOS
Image Stabilization	Digital, 5-Axis
Built-In ND Filter	Mechanical Filter Wheel with 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64), 8-Stop (1/256), 10-Stop (1/1024) ND Filters
Internal Filter Holder	No
Capture Type	Stills & Video

Exposure Control

Shutter Type	Electronic Rolling Shutter
Shutter Speed	1/2000 to 1 Second
ISO Sensitivity Range	100 to 102,400
Shutter Angle	11.25 to 360°
Advertised Dynamic Range	16 Stops
Signal-to-Noise Ratio	67 dB
White Balance	2000 to 15,000K Presets: AWB, Daylight, Set A, Set B, Tungsten

Video Capture

Internal Recording Modes	Cinema RAW Light 12-Bit UHD 6K (6000 x 3164) from 1 to 29.97 fps [553 to 639 Mb/s VBR] 4368 x 2304 from 1 to 29.97 fps [678 Mb/s VBR] XF-AVC Intra 4:2:2 10-Bit 4096 x 2160 from 1 to 60.00 fps [240 to 600 Mb/s VBR] 3840 x 2160 from 1 to 60.00 fps [240 to 600 Mb/s VBR] 2048 x 2160 from 1 to 120 fps [120 to 300 Mb/s VBR] 1920 x 1080 from 1 to 120 fps [120 to 300 Mb/s VBR] XF-AVC Long GOP 4:2:2 10-Bit 4096 x 2160 from 1 to 120 fps [130 to 250 Mb/s VBR] 3840 x 2160 from 1 to 120 fps [130 to 250 Mb/s VBR] 2048 x 1080 from 1 to 180 fps [50 Mb/s VBR] 1920 x 1080 from 1 to 180 fps [25 to 50 Mb/s VBR] XF-AVC S Intra 4:2:2 10-Bit 4096 x 2160 from 1 to 60.00 fps [240 to 1200 Mb/s VBR] 3840 x 2160 from 1 to 60.00 fps [240 to 1200 Mb/s VBR] 2048 x 1080 from 1 to 120 fps [120 to 300 Mb/s VBR] 1920 x 1080 from 1 to 120 fps [120 to 300 Mb/s VBR] XF-AVC S Long GOP 4:2:2 10-Bit 4096 x 2160 from 1 to 120 fps [150 to 250 Mb/s VBR] 3840 x 2160 from 1 to 120 fps [150 to 250 Mb/s VBR] 2048 x 1080 from 1 to 180 fps [50 Mb/s VBR] 1920 x 1080 from 1 to 180 fps [50 Mb/s VBR] XF-AVC S Long GOP 4:2:0 8-Bit 4096 x 2160 from 1 to 120 fps [100 to 150 Mb/s VBR] 3840 x 2160 from 1 to 120 fps [100 to 150 Mb/s VBR] 2048 x 1080 from 1 to 180 fps [35 Mb/s VBR] 1920 x 1080 from 1 to 180 fps [35 Mb/s VBR] XF-HEVC S Long GOP 4:2:2/4:2:0 10-Bit 4096 x 2160 from 1 to 120 fps [135 to 225 Mb/s VBR] 3840 x 2160 from 1 to 120 fps [135 to 225 Mb/s VBR] 2048 x 1080 from 1 to 120 fps [35 Mb/s VBR] 1920 x 1080 from 1 to 120 fps [35 Mb/s VBR]
External Recording Modes	SDI/BNC / HDMI / USB 4096 x 2160
Recording Sensor Crop	Crops to Output Resolution When Using Super35 Mode
Fast-/Slow-Motion Support	Yes
Gamma Curve	Canon Log 2, Canon Log 3, HDR-HLG, Rec709, Rec2020
Broadcast Output	NTSC/PAL
Built-In Microphone	Stereo
Audio Recording	Cinema RAW Light: 4-Channel 24-Bit 48 kHz LPCM Audio XF-AVC: 4-Channel 24-Bit 48 kHz LPCM Audio XF-AVC S, XF-HEVC S: 4-Channel 24-Bit 48 kHz LPCM Audio XF-AVC S, XF-HEVC S: 2-Channel 16-Bit 48 kHz AAC Audio
IP Streaming	H.264, MPEG2, RTP, RTSP, SRT, UDP 1920 x 1080 at 50i, 50p, 59.94i, 59.94p (4.0 to 9.0 Mb/s)

Still Image Capture

Image File Format

JPEG

Interface

Media/Memory Card Slot	Slot 1: SD/SDHC/SDXC Slot 2: SD/SDHC/SDXC
Video I/O	1x BNC (12G-SDI) Output 1x BNC (3G-SDI) Monitor Output 1x HDMI (Unspecified Signal) Output
Audio I/O	2x Mini XLR Input 1x 1/8" / 3.5 mm TRS Stereo Headphone Output 1x 1/8" / 3.5 mm TRS Stereo Microphone Input on Camera Body
Power I/O	1x Barrel (23.7 to 25VDC) Input
Other I/O	1x RJ45 (XC) Control 1x USB-C Monitor 1x BNC (Timecode) 1x 2.5 mm Sub-Mini (LANC) Control
Wireless	2.4 / 5 GHz Wi-Fi 5 (802.11ac)
Mobile App Compatible	Yes: iOS Only App Name: Remote Camera Control App Functionality: Adjust Settings, Remote Control, View Live Feed
Global Positioning (GPS, GLONASS, etc.)	No

Monitor

Display Type	Included External Touchscreen LCD
Display Size	3.5"
Resolution	1280 x 720

Focus

Focus Type	Auto and Manual Focus
Focus Mode	Continuous-Servo AF, Focus Lock AF Area Mode, One-Shot AF

General

Operating Conditions	32 to 104°F / 0 to 40°C up to 85% Humidity
Storage Conditions	23 to 113°F / -5 to 45°C up to 60% Humidity
Battery Type	Canon BP-AN Series
Shoe Mount	1x Intelligent Hot Shoe
Tripod Mounting Thread	1x 3/8"-16 Female 2x 1/4"-20 Female
Dimensions (W x H x D)	6.3 x 5.4 x 4.6" / 160 x 138 x 116 mm 10.9 x 6.8 x 6.3" / 276 x 173 x 160 mm (With Handle, Included Battery, Mic Holder)
Weight	2.89 lb / 1.31 kg (Body Only) 3.406 lb / 1.545 kg (With Battery, Handle)
