PortKeys BM5 III WR 5.5" HDMI Touchscreen Monitor w/ Cabled Camera Control

Code: BLO/PK-BM5-III-WR
$1,285.00

The Portkeys BM5 III WR is a lightweight, rugged 5.5-inch Wide Color Gamut on-camera monitor with 2,200nits of brightness, HDMI/SDI video inputs, one SDI output with HDMI cross-conversion and wired/wireless camera control capabilities.

Add to Cart

Found this item cheaper elsewhere? Let us know

ENQUIRE NOW

Got a question about this product?
Send us a message

Out of Stock - Call for availability

Or get notified when back in stock

OK, we'll notify you when PortKeys BM5 III WR 5.5" HDMI Touchscreen Monitor w/ Cabled Camera Control is back in stock.

What's In The Box?

  • 1x BM5 III Monitor
  • 1x Power Cord 100cm(4-pin aviation to D-tap)
  • 1x Power Cord 40cm(4-pin aviation to DC)
  • 1x L-Type Antenna
  • 1x LANC Control Cable 40cm
  • 1x Type-C Control Cable 40cm
  • 1x Warm Prompt Card
  • 1x Safety Box
  • 1x USB (Manual, 3D LUTs, Firmware Inside)

    • The Portkeys BM5 III WR is a lightweight, rugged 5.5-inch Wide Color Gamut on-camera monitor with 2,200nits of brightness, HDMI/SDI video inputs, one SDI output with HDMI cross-conversion and wired/wireless camera control capabilities.

    Key features

    • 5.5-inch, 10-bit panel with a resolution of 1920 x 1080 and a 1000:1 contrast ratio.
    • Daylight-viewable with a maximum brightness of 2,200nits.
    • 1 x 3G-SDI input, 1 x HDMI input, 1 x 3G-SDI output with cross-conversion.
    • Professional monitoring tools: Waveform, Vectorscope, Peaking, ARRI False Color.
    • 3D LUT monitoring and 3D LUT SDI output capabilities.
    • RED Approved: wireless camera control for the RED Komodo and V-RAPTOR.
    • Wireless camera control for most Sony and Blackmagic Design cameras.
    • Wired camera control for Sony, Canon, Panasonic, BMD, and ZCAM E2.
    • TILTA Nucleus N/M wireless follow focus wired control.
    • Built-in Sony NP-F style battery plate.
    • 4-pin 7.4V-24V power input for external power (D-Tap cable included).
    • Lightweight and rugged aluminum housing: only 376g/13.2oz.
    Specifications
    Screen Size 5.5″
    Dimension 145.4*120.9*38.5mm
    Viewing Angle 178°H/178°V
    Brightness 2200nit
    Resolution 1920*1080
    Contrast Ratio 1000:1
    Weight 383g
    Color Depth 10bit(8+2 FRC)
    Maximum Power 14W
    Material Aluminum alloy + Toughened glass
    Input Voltage 4pin Aviation Connector IN 7.4-24V
    Output Voltage 4pin Aviation Connector OUT 7.4V(NPF)
    Video Signal Input SDI/HDMI
    Video Signal Output SDI
    Motor Control Port 5pin Aviation Connector
    Camera Control Port Mini USB 10pin
    USB-A Upgrade Firmware/Load LUT
    Antenna 2.4G
    HDMI Signal 1920*1080p@23.97Hz,24Hz,25Hz,
    29.97Hz,30Hz,50Hz,59.94Hz,60Hz
    1920*1080psf@23.97Hz,24Hz,
    25Hz,29.97Hz,30Hz
    1920*1080i@50Hz,59.94Hz,60Hz
    1280*720p@50Hz,59.94Hz,60Hz
    720*576i@50Hz
    720*576p@50Hz
    720*480p@59.94Hz,60Hz
    720*480i@59.94Hz,60Hz
    SDI Signal 1920*1080p@50fps,59.94fps,60fps
    1920*1080p@50Hz,59.94Hz,60Hz
    1920*1080p@23.98Hz,24Hz,25Hz,
    29.94Hz,30Hz YUV444/YUV422/RGB444 1920*1080i@50Hz,59.94Hz,60Hz
    YUV444/YUV422/RGB444
    1280*720p@50Hz,59.94Hz,60Hz
    YUV444/YUv422/RGB444
